Achieve Perfect Curves, Faster and Smarter with CNC
Premium CNC Wire Bender, Wire Forming Machine & Custom Solutions.
OMEX manufactures high-efficiency-cost bending solutions to suit the specific applications of every client. This advanced technology, along with service, parts and training from our team of industry experts, enables you to improve speed and accuracy and produce better results for your customers.
Innovative Solutions, Built for You.
Every OMEX solution is designed and engineered to support
your organization’s requirements and maximize:
PRECISION
EFFICIENCY
PERFORMANCE
DURABILITY
PRODUCTIVITY
| No. | ITEM | OM1026 | OM1045 | OM1245 | OM1260 | OM-7-60 | OM-7-100 | OM-7-12 |
|---|---|---|---|---|---|---|---|---|
| 1 | Wire Size | 0.2-2.5mm | 1.2-4.5mm | 1.2-4.5mm | 2.0-6.0 mm | 2.0-6.0 mm | 3.5-10 mm | 4-12 MM |
| 2 | 2D/3D | 3D | 3D | 3D | 3D | 2D | 2D | 2D |
| 3 | Axis Quantity | 10 Axis | 10 Axis | 12 Axis | 12 Axis | 7 Axis | 7 Axis | 7 Axis |
| 4 | Max. Feeding Speed | 100m/per min | 100m/per min | 100m/per min | 100m/per min | 100m/per min | 100m/per min | 100m/per min |
| 5 | Cam Servo Power | 0.75kw*8 | 1.2kw*8 | 1.2kw*8 | 2.7kw*8 | / | / | / |
| 6 | Feeding Servo Power | 2.7kw | 5.5kw | 5.5kw | 11kw | 2.7kw | 4.5kw | 7.5kw |
| 7 | Rotating Servo Power | 0.75kw | 1.2kw | 1.2kw | 1.5kw | 1.2kw | 2.7kw | 4.5kw |
| 8 | Servo Brand | Panasonic | Panasonic | Panasonic | Panasonic | Sanyo | Sanyo | Sanyo |
| 9 | Machine Weight | 1200KG | 2100KG | 3000KG | 5300KG | 2000KG | 3800KG | 4300KG |
Features that We are Super Proud of
CNC 3D Full Automatic Wire Bending Machine
- Equipped with 10-12 electric CNC axes
- Camless Design for Spring
- CNC wire benders can offer one of the highest performance solutions according to your request
Specially Designed for Spring Forming
- Multiple Axis Machine Available to Meet Your Request
- Suitable for 2-10mm Spring
- Easy Operation with Software Working
- Production of small to medium size quantities
2D CNC Wire Bending Machine
- 32M large program space to store up to 10000 programs
- 24-point input, support for high-speed probe detection input, wire feed frame winding, with broken wire, off-line alarm detection inputs
- Industrial PC assorted with touch-screen display
- with USB port, easy for data transfer
- Suitable for wire, spring and flat material
- Punching function as option for easy working
3D CNC Wire Bending Machine
- High-speed motors from Japan and speed reducer from Germany
- Production speed 25% higher than that of similar products in market
- Wire feed and arm, both separate and together, when turning the head really do not turn the line, it can achieve smaller outer diameter arc and multi-circle product forming.
From Concept to Final Machine
From each item part manufacturing and machining, we have bulks of spare parts for each standard mode to make sure quick delivery time and quality control. Each equipment will be checked and tested before shipping and packed well to delivery to your hand safely and newly. We are welcome to any big order or urgent machine order to be ready in in stock for your on time to help each partner with support and efficiency. Are you ready to get high performance-cost machines?
Want to learn more about our
capabilities and discuss a solution that
meets your goals?
Check the below technical parameter
0R fill out the form
below to speak with a member of our team!
Join Our 1000+ Satisfied Clients Worldwide
Why They Choose OMEX CNC Wire Bender
Request A Free Quote
We'd like to work with You
Send us a message if you have any questions or request a quote. Our experts will give you a reply within 12 hours and help you select the right machine model you need.
